44 series V-shaped guide rail series products belong to medium-load guide rails, which have various shapes such as circular guide rails, arc guide rails, linear guide rails, etc., with high precision and long service life.
Surface hardness of the Guideway surface: HRC55-58
Designed weight: < 80 kg
Theoretical weight: <120 kg
Surface plane accuracy*: ±0.01 mm
*When the size is larger, there is the possibility of deformation, and this accuracy is related to the accuracy of the guideway mounting planeduring use.
Model | Basic Scale（mm） | ||||||||
φA | φB | φC | D | a1/Angle | a2/Angle | a3/Angle | N*H(Counterbore) | E | |
TO44D468 | 468 | 424 | 512 |
18 | 4 | 11.25 | 22.5 | 24*M6 |
44 |
TO44D612 | 612 | 568 | 656 | 4 | 11.25 | 22.5 | 24*M6 | ||
TO44D800 | 800 | 756 | 844 | 4 | 11.25 | 22.5 | 24*M6 | ||
TO44D1000 | 1000 | 956 | 1044 | 3 | 9 | 18 | 28*M8 | ||
Note: The whole circular arc guide can be cut into arc guides of different radians, which can be used alone or in combination with wheels or straight rails to form a closed-loop or open-loop circular guide System.
