25 series 180 arc guide rail. V-Type guide rail series products belong to light-load guide rails, which have various shapes such as circular guide rails, arc guide rails, linear guide rails, etc, service life.
Hotline
(86)752-2123226 / 18928325808
Product Display
product
News Center
News Center
Surface hardness of the Guideway surface: HRC 55-58
Designed weight: < 30 kg
Theoretical weight: <50 kg
Surface plane accuracy*: ±0.01 mm
*When the size is larger, there is the possibility of deformation, and this accuracy is related to the accuracy of the guideway mounting planeduring use.
Model | Basic scale（mm） | ||||||||
φA | φB | φC | D | a1/Angle | a2/Angle | a3/Angle | N*H(Counterbore) | E | |
HC25D200 | 200 | 174.6 | 225.4 |
16 | 7 | 15 | 30 | 10*M6 |
25.4 |
HC25D255 | 255 | 229.6 | 280.4 | 7 | 15 | 30 | 10*M6 | ||
HC25D300 | 300 | 274.6 | 325.4 | 7 | 15 | 30 | 10*M6 | ||
HC25D351 | 351 | 325.6 | 376.4 | 6 | 15 | 30 | 10*M6 | ||
HC25D400 | 400 | 374.6 | 425.4 | 6 | 15 | 30 | 10*M6 | ||
HC25D468 | 468 | 442.6 | 493.4 | 5 | 15 | 30 | 10*M6 | ||
HC25D500 | 500 | 474.6 | 525.4 | 5 | 15 | 30 | 10*M6 | ||
HC25D600 | 600 | 574.6 | 625.4 | 5 | 11.25 | 22.5 | 12*M8 | ||
HC25D700 | 700 | 674.6 | 725.4 | 3 | 11.25 | 22.5 | 12*M8 | ||
HC25D800 | 800 | 774.6 | 825.4 | 3 | 9 | 18 | 14*M8 | ||
HC25D900 | 900 | 874.6 | 925.4 | 3 | 9 | 18 | 14*M8 | ||
HC25D1000 | 1000 | 974.6 | 1025.4 | 3 | 9 | 18 | 14*M8 | ||
Note: The above is a conventional standard ruler arc guide rail, which can be customized with different diameters according to customer needs.The opening has a fixed rule, please call for details.
