76 series 180 degrees guide rail. V-shaped guide rail series products belong to hight-load guide rails, which have various shapes such as circular guide rails, arc guide rails, linear guide rails, etc., with high precision and long service life.
Surface hardness of the Guideway surface: HRC55-58
Designed weight: < 300 kg
Theoretical weight: <500 kg
Surface plane accuracy*: ±0.01 mm
*When the size is larger, there is the possibility of deformation, and this accuracy is related to the accuracy of the guideway mounting planeduring use.
Model | Basic Scale（mm） | ||||||||
φA | φB | φC | D | a1/Angle | a2/Angle | a3/Angle | N*H(Counterbore) | E | |
HC76D500 | 500 | 424 | 576 |
30 | 5 | 10 | 30 | 10*M8 |
76 |
HC76D700 | 700 | 624 | 776 | 3 | 9 | 18 | 12*M8 | ||
HC76D900 | 900 | 824 | 976 | 3 | 9 | 18 | 14*M8 | ||
HC76D1000 | 1000 | 924 | 1076 | 3 | 9 | 18 | 14*M8 | ||
HC76D1100 | 1100 | 1024 | 1176 | 3 | 9 | 18 | 14*M8 | ||
HC76D1200 | 1200 | 1124 | 1276 | 3 | 9 | 18 | 14*M8 | ||
HC76D1267 | 1267 | 1191 | 1343 | 3 | 9 | 18 | 14*M8 | ||
HC76D1300 | 1300 | 1224 | 1376 | 3 | 9 | 18 | 14*M8 | ||
HC76D1400 | 1400 | 1324 | 1476 | 3 | 9 | 18 | 14*M8 | ||
HC76D1500 | 1500 | 1424 | 1576 | 3 | 9 | 18 | 14*M8 | ||
HC76D1560 | 1560 | 1484 | 1636 | 3 | 9 | 18 | 14*M8 | ||
Note: The above is a conventional standard ruler arc guide rail, which can be customized with different diameters according to customer needs.The opening has a fixed rule, please call for details.
