76 series V-shaped guide series products belong to heavy-duty guide rails. They have various shapes such as circular guide rails, arc guide rails, linear guide rails, etc., with high precision and service life.
Surface hardness of the Guideway surface: HRC55-58
Designed weight: < 300 kg
Theoretical weight: <500 kg
Surface plane accuracy*: ±0.01 mm
*When the size is larger, there is the possibility of deformation, and this accuracy is related to the accuracy of the guideway mounting planeduring use.
Model | Basic Scale（mm） | ||||||||
φA | φB | φC | D | a1/Angle | a2/Angle | a3/Angle | N*H(Counterbore) | E | |
TO76D500 | 500 | 424 | 576 |
30 | 5 | 10 | 30 | 20*M8 |
76 |
TO76D700 | 700 | 624 | 776 | 3 | 9 | 18 | 24*M8 | ||
TO76D900 | 900 | 824 | 976 | 3 | 9 | 18 | 28*M8 | ||
TO76D1000 | 1000 | 924 | 1076 | 3 | 9 | 18 | 28*M8 | ||
TO76D1100 | 1100 | 1024 | 1176 | 3 | 9 | 18 | 28*M8 | ||
TO76D1200 | 1200 | 1124 | 1276 | 3 | 9 | 18 | 28*M8 | ||
TO76D1267 | 1267 | 1191 | 1343 | 3 | 9 | 18 | 28*M8 | ||
TO76D1300 | 1300 | 1224 | 1376 | 3 | 9 | 18 | 28*M8 | ||
TO76D1400 | 1400 | 1324 | 1476 | 3 | 9 | 18 | 28*M8 | ||
TO76D1500 | 1500 | 1424 | 1576 | 3 | 9 | 18 | 28*M8 | ||
TO76D1560 | 1560 | 1484 | 1636 | 3 | 9 | 18 | 28*M8 | ||
Note: The whole circular arc guide can be cut into arc guides of different radians, which can be used alone or in combination with wheels or straight rails to form a closed-loop or open-loop circular guide System. The above is the conventional standard ruler arc guide rail, in which D500~D1000 For conventional ware house products, other ruler diameters can be customized according to customer needs.
